TECHNICAL SPECIFICATION
| Model | JSARCS - 100 | JSARCS - 150 | JSARCS - 200 | |
| Output/Hour* | 3600 To 6000 Bottles | 3600 To 9000 Bottles | 4000 To 12000 Bottles | |
| Direction Of Movement | Left To Right | |||
| No. Of Heads | 4 Nos. | 6 Nos. | 8 Nos. | |
| Electrical Specifications** | Main Motor | 1.5 HP / 415 Volts / 50 Hz. | 2 HP / 415 Volts / 50 Hz. | |
| Cap Feeding Bowl | 0.25 HP / 415 Volts / 50 Hz. | |||
| Height Of Conveyor** | 860mm To 910mm | |||
SALIENT FEATURES :
- No Container No Cap Arrangement.
- S.S. Elegantly Matt Finished Body.
- Adjustable Height Of Conveyor Belt, To Align With Other Machines Of The Line.
- Sealing Pressure Can Be Varied To Suit Different Gauges And Size Of Caps.
- Low Noise Level, Low Power Consumption.
- Self Lubricating UHMW-PE Guide Profile For SS Slat Chain Provides Low Friction Wear Surface, Smooth And Noiseless Conveying.
- S.S. Cladding Or Hard Chrome Platting Of All Exposed Parts To Ensure Long Life And Resistance Against Corrosion.
- Universal Coupling For Quick And Easy Setting Of In-feed Worm.
- Adjustable Bottle Height Gauge For Easy And Quick Setting.
