TECHNICAL SPECIFICATION
| Model | JSALF - 100 | JSALF - 150 | JSALF - 200 | |
| Output/Hour* | 2400 To 6000* | 3600 To 9000* | 5000 To 12000* | |
| Direction Of Movement | Left To Right | |||
| No. Of Heads/Syringes | 4 Nos. | 6 Nos. | 8 Nos. | |
| Fill Size*** | 5 Ml To 1000 Ml | |||
| Electrical Specifications** | Main Motor | 1 HP / 415 Volts / 50 Hz. | 1.5 HP / 415 Volts / 50 Hz. | |
| Conveyor | 0.5 HP / 415 Volts / 50 Hz. | |||
| Height Of Conveyor** | 860mm To 910mm Adjustable | |||
SALIENT FEATURES :
- ± Filling Accuracy On Single Dose.
- No Bottle No Filling System.
- Rigid Vibration, Free Construction For Trouble Free Performance.
- S.S. Elegantly Matt Finished Body.
- Elegant And Easy Control Panel For Total Control On Operation.
- Minimum Changeover Time, From One Size To Another Container Or Fill Size.
- Self Lubricating UHMW-PE Guide Profile For SS Slat Chain Provides Low Friction Wear Surface, Smooth And Noiseless Conveying.
- Pneumatic Bottle Stopping Arrangement.
- Synchronized Two Nos. A/c Drive For Main Motor & Conveyor Belt.
- Safety Guard For Conveyor Gear Box, Motor And Pneumatic Cylinders.
- Inbuilt Protection Against Over Current, Voltage Fluctuation, Short Circuit In AC Frequency Drive.
