TECHNICAL SPECIFICATION
| Model | JSARCS - 150 | |
| Output/Hour* | 1000 To 3000 Bottles | |
| Direction Of Movement | Left To Right | |
| No. Of Sealing Head | 1 Nos. | |
| Electrical Specifications** | Main Motor | 1 HP / 415 Volts / 50 Hz. |
| Cup Feeding Bowl | 300 Watt | |
| Height Of Conveyor** | 860mm To 910mm | |
SALIENT FEATURES :
- No Container No Cup Arrangement.
- SS Elegantly Matt Finished Body.
- Single Motor Synchronizes Conveyor, Star Wheel & Platform Turret.
- Adjustable Height Of Conveyor Belt, To Align With Other Machines Of The Line.
- Sealing Pressure Can Be Varied To Suit Different Gauges And Size Of Caps.
- Low Noise Level, Low Power Consumption.
- Self Lubricating UHMW-PE Guide Profile For Low Friction Wear Surface, Smooth And Noiseless Conveying.
- SS Cladding Or Hard Chrome Platting Of All Exposed Parts To Ensure Long Life And Resistance Against Corrosion.
- Synchronized A/C Drivers To Synchronize, Conveyor, Star Wheel And Platform Turret & Capping Bowl.
- Adjustable Bottle Height Gauge For Easy And Quick Setting.
